QN coaxial connectors are available with 50ohm impedance.
The frequency range extends to 11GHz, depending on the connector and cable type, however most of
the QN connectors are return loss optimised for frequencies up to 6GHz.
The interface is based on the inner dimensions of the N connector, but instead of a threaded coupling
mechanism, a snap-lock mechanism is used.
The QN interface has a very similar performance to the N, but in addition it offers an easier, faster and
safer coupling mechanism, a snap-lock mechanism is used.
